Function
It is suitable for compacting steel chips, cast iron chips, copper chips and aluminum chips into high density cylindrical cladding blocks for recycling and smelting, especially casting iron chips can replace cast iron after compacting.
Features
1. Hydraulic drive, high working efficiency.
2. Smooth operation, only simple equipment foundation.
3. Adopt PLC control, can choose manual or automatic operation.
Technical Specification
|
Model
|
Cyl.Force(ton)
|
Press Mould(mm)
|
Briquet Size(mm)
|
Production Rate(kg/hr)
|
Power(kw)
|
|
Y83W-630
|
630
|
Φ200×550
|
Φ200×(160~200)
|
4500~5500
|
90
|
|
Y83W-1000
|
1000
|
Φ240×600
|
Φ240×(190~240)
|
9000~11000
|
225
|
|
Y83W-1250
|
1250
|
Φ300×700
|
Φ300×(220~270)
|
15000~18000
|
320
|
Technical Specification
|
Model
|
Cyl.Force(ton)
|
Press Mould(mm)
|
Briquet Size(mm)
|
Production Rate(kg/hr)
|
Power(kw)
|
|
Y83-250
|
250
|
Φ110×180
|
Φ110×(50~70)
|
600~800
|
22
|
|
Φ120×180
|
Φ120×(50~70)
|
|
Y83-315
|
315
|
Φ120×180
|
Φ120×(50~70)
|
800~1100
|
30
|
|
Φ140×180
|
Φ140×(50~70)
|
|
Y83-400
|
400
|
Φ140×300
|
Φ140×(70~100)
|
1300~1600
|
37
|
|
Φ160×300
|
Φ160×(70~100)
|
|
Y83-500
|
500
|
Φ160×300
|
Φ160×(70~100)
|
1700~2300
|
45
|
|
Φ180×300
|
Φ180×(70~100)
|
|
Y83-630
|
630
|
Φ180×400
|
Φ180×(100~140)
|
2800~3500
|
74
|
|
Φ200×400
|
Φ200×(100~140)
|
